Carbide Application Equipment

MODEL 950

Rocklinizer Model 950 / 950E – Deposits from .0001″ to .010″ and higher in a single application, controllable within .0001” by machine setting. Approximately 30 lbs. (13.2 kg.)

The Model 950 Rotary Applicator is automatically triggered when the electrode is placed in contact with the workpiece, or manually triggered by the operator.

• Faster Application
• Widest Deposit Range
• Rotary Applicator
• Integrated Air Pump
• Digital Readout
• Touch Panel Controls
• 100% Portable

MODEL 850

Rocklinizer Model 850 / 850E – Deposits from .0002″ to .007″ in a single application, controllable within .0001” by machine setting. Approximately 30 lbs. (13.2 kg.)

The Model 850 Rotary Applicator is automatically triggered when the electrode is placed in contact with the workpiece, or manually triggered by the operator.

• Faster Application
• Rotary Applicator
• Digital Readout
• Touch Panel Controls
• 100% Portable

MODEL 500

500 / 500E – Deposits from .0001″ to .002″ in a single application, controllable within .0001″ by machine dial setting.
Approximately 33 lbs. (14.5 kg.)

Model 500 Applicator is automatically triggered when electrode is placed in contact with workpiece, or manually triggered by the operator.

KNIFE MAKER’S MODEL

380AKM / 380AKME Knife Maker’s Model –
Deposits are available from .0001” to .001” in a single application, controllable within .0001” by machine dial setting.
Approximately 28 lbs. (12.7 kg.)

High Endurance Knife Edge System:

• Carbide Treated Wear Protected Edge.
• Self-Sharpens With Continued Use.
